Model NO | LM3014-WN240-24V-8MM |
LED Type | SMD3014 |
Voltage(V) | DC24V |
LED Qty/m | 240LED/M |
PCB Width | 8MM |
Rated Power(W) | 16.8W/M(Customized power available) |
Wavelength/CCT | Ra80: 2700K(1596LM/M), 3000K(1629.6LM/M), 4000K(1680LM/M), 6000K(1764LM/M) |
Cutting Unit | 25MM (6LEDs/cutting) |
IP Rate | IP20/IP54/IP65 |
LED Chip Brand | SANAN, EPISTAR, LUMILEDS, SAMSUNG |
LEDs Material | Double high thick 99.99% Gold Wire, Copper holder |
LEDs Supplier | HONGLITRONIC, LUMILEDS, SAMSUNG |
CRI(RA>) | 80+, 90+ |
Color Tempertature | 2200K~7000K |
Package(m/roll) | 5M, 10M, 25M, 50M |
Certificate | UL, CE, FCC, ROHS, UKCA , CB, ISO9001 |
Warranty | 3~5 Years |
